Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
  • Charger l'image dans la galerie, Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
  • Charger l'image dans la galerie, Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
  • Charger l'image dans la galerie, Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
  • Charger l'image dans la galerie, Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
  • Charger l'image dans la galerie, Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
  • Charger l'image dans la galerie, Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF
  • Charger l'image dans la galerie, Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF

Enregistreur de caméras32CH 4K Face CCTV NVR Board Hi3536 2 SATA Ports ONVIF

Prix normal
€61,78
Prix réduit
€61,78
Prix normal
€31,78
Épuisé
Prix unitaire
par
Taxes incluses.

1. HDD question: We recommend use the Newest HDD. Use the security HDD will work more better. PC HDD most can not work. 2.IP Camera 264 and 265 question: This one only support the xmeye IP camera H.265, if you use the dahua or hik camera, nvr will not match all of their cameras and not support h.265 3. VGA and HDMI question: NVR have a defult display resolution,Your monitor must use the same resolution then will work first time. The second you can change the nvr output resolution as you need.

Face Record/Face Detection/Face Playback Record every face that appears on the lens, without missing any details. You need use the Face Detction Function IP Camera

Newest Firmware Support 32CH 4K IP Camera

Langauages: English,Russian,Italian,Portuguese,Spanish,French,Germany.,etc...

Motion Detection & Email Alert/Record when motion is detected, the NVR can send email or start record to the hard disk without missing any important events.

Max Support the 4K Display

Advanced H.265++ Video Compression H.265 (HEVC) doubles the coding efficiency compared with its predecessor H.264. That means H.265++ video saves around 70% of the bit rate at the same quality of coding.

Easy remote access Anytime anywhere P2P technology supports remote access on the mobile device,Just intall the APP on your phone by scanning the QR cade or storing from the APP View the camera remotely anytime, any where. PC use the www.xmeye.net to visit the camera.


Model
NBD8025R-UL

System
Main processor
Hi3536
H.265++
Operating System
Embedded Linux
System resources
Simultaneous multi-channel real-time recording, playback, network operation, USB backup

Interface
Operator interface
16-bit true color graphic menu operation interface, support mouse operation
Preview
1/4/9/16/25/32





Video
Video input (IP)
32CH 4K (5MP,4MP,3MP,2MP,1MP Xmeye camera and same onvif camera support)
Access bandwidth
300Mbps
Forwarding bandwidth
240Mbps
Video compression
H.265++/H.264
Display quality
Max:4K
Playback quality
4K
Decode
4K
Motion detection
Support(depend on camera)

Audio
Audio compression
G.711A
Intercom
support

Record & playback
Recording mode
Manual>Alarm>Dynamic Detection>Timing
Local payback
4K
Search mode
Search by Time/Calendar/Event/Channel
Record storage
HDD,Network
Backup mode
Network backup, USB hard disk, USB burner, SATA burner




External interface
Video output
1ch VGA,1ch HDMI HD output
Audio I/O
1/1
Alarm I/O
0/0
Network interface
1*RJ45 10M/100M/1000M Adaptive Ethernet port
USB interface
3G,Wifi
2*USB2.0 ports
Support 3G,Wifi, please ask seller which 3G,Wifi adapter can use.
HDD
2 SATA(Up to 8TB for each disk)
ESATA
No
Cooler
Include(The cooler is contact to the board by head sink,if sometimes it take down by shipping, please contact it by yourself, we will not accept any dispute just because of this.)



Other
ONVIF
Support
Power supply
12V/6A , Adapter is not include, you need buy extra,
​6A is for two HDD, if you need one HDD,please confirm how much ampere
Power Consumption
<10W(Without HDD)
Work environment
Temperature:0℃-+55℃ , Humidity:10%-90%RH , Atm:86kpa-106kp
Dimension
135mm*81mm
Weight
A total of about 103g



New Style Win10 Menu
