Interphone Wifi Vidéo RFID

Prix normal
€359,75
Prix réduit
€359,75
Prix normal
€259,75
Épuisé
Prix unitaire
par
Taxes incluses.



Notre système de sonnette d'interphone vidéo est uniquement alimenté par la caméra extérieure et l'unité intérieure n'a pas besoin d'être connectée à l'alimentation électrique. Il est facile à installer et a une belle apparence.

Système d'interphone vidéo WOLILIWO WIFI

Cet ensemble de produits est Record Wired Wifi 2/3/4 Apartments Video Door Phone Intercom System.L'écran équipé d'un écran TFT-LCD haute définition importé, avec une image claire et des couleurs ture, .Il prend en charge le déverrouillage à un bouton et un- bouton répondant etc. Interphone, fonction de déverrouillage à distance.

1

Features:
*9 inch high definition LCD monitor,with taking picture,visitor records  function.

*Outdoor unit use 700TVL high-definition camera,indoor monitor is with functions of monitor,intercom,unlock,hands-free,take pictures automatically and don't disturb function.

*Support mobile APP with monitor,indoor monitor can take pictures and video record,support Max 32G TF card(TF card is not included).

*One device can be added and connected to several mobile phones in the meantime,and up to four mobile phones are allowed to open and view the outdoor unit in the meantime

*Indoor monitor volumes and image brightness & color can be adjusted by your own preference.

*WIFI Video Door Phone:Indoor monitor can connect to wireless WIFI router.

*Anti-oxidation and wear-resistant metal outdoor unit,Embedded installation.

*Only outdoor camera to connect the power supply,  Indoor unit does not need power supply.



9 inch Wifi video intercom system


1. Real-time control by smart phone , unlock ,videos/images record , 2 way talk
2. Smart phone connect to monitor,  available to monitor outdoor cameras
3. need to install LookCam APP in your phone
4. monitor connect doorbells and cameras by wires
5.  after connect successfuly,  you can realtime connect this video intercom by wifi or 4G network
6. support videos record to memory card
7. monitor maximum support 32GB external TF memory card(Not include TF card)


2
Ha3a4fb1237684132a820e28354d511dfp




Outdoor camera - Product Specs :

camera sensor :  1/3" CMOS , 700TV-Line
Night Vision :  IR light
Electronic lock :  support
Material :Metal panel
Waterproof  : support
Operation Temp:  -20degree  +60degree
Installation :Embedded installation
The angle of the lens can be adjusted
Only outdoor camera to connect the power supply,  Indoor unit does not need power supply.

 660门口机的参数

660  1

APP Unlock & Remote Control

When someone press the outdoor camera, the screen of the indoor unit will ring and display the scene outside the outdoor camera.Inadditional,the mobile phone will also have push messages. You can speak to visitors, unlock, etc from anywhere.. can and never miss visitors' information.Support Android 6.0 and iOS 8.0 or above mobile phone system.

4



Monitoring function
You can check the situation outside the outdoor camera through the indoor unit or mobile phone at any time.
5


Automatically Record Video or Take Pictures
When the outdoor unit calls the indoor unit, the indoor unit can automatically record video or take pictures (this function needs to be set on the interface).
The indoor unit supports a maximum of 32GB memory card(Not include)
6



Waterproof & Night Vision Camera
The Outdoor doorbell is constructed with a aluminum front panel for protection from vandalism, while waterproofing protects from the rain or snow.
700TVL IR night vision camera makes you to see clearly who rings the bell even at night, it can capture images in low-illumination environment.Can automatically balance the light and dark area of the video to give you a better night vision experience.
7




One power connection

Only the outdoor camera to connect a power supply, indoor unit does not need to connect the power supply,  Easy to connection.

8(2)





Indoor monitor & Outdoor camera Wiring diagram

660X2-V90S-WIFI





11(2)







About Wireless Connetion:

The monitor support WiFi network(only connect with 2.4GHZ router band), but the indoor monitor and doorbell is Wired.The monitor connected to the router can transmit WiFi signal, and you can control the video intercom system on your mobile phone under this WiFi signal.

About the extension wire:

The extension wires is not included in the box, there are the 4 core connectors for you connect the extension wires.You can use RVV4/Cat5/Cat6 wires to extend the monitor to doorbell.

 The longest connection distance from the outdoor camera to the indoor unit is 50 meters.

There are several ways to open the door lock when you are outside the door: using the RFID keyfobs or the remote control set. This item comes with 4 RFID keyfobs(including added keyfob and deleted keyfob) . Besides, if you need more RFID keyfobs, you can add the quantity of the RFID keyfob as you like.



idfob


The outdoor unit has RFID reader, which supports max 500 RFID cards/fobs. It is easy to add new cards and delete old cards.

(Note: the function of the added card and delete keyfob (the added/delete keyfob can not unlock the door lock)



What is Included

10

Very Important:

Please leave us message which type of the power plug you want, otherwise, we will send EU type by default

电源的图片
